R180-II
Model: R180-II
Overview
Setting the standard for value-class thermal receipt printers, TEAMSable delivers an affordable POS printer that provides all popular connection interfaces, including USB, Serial and Ethernet, with state-of-the-art speed and best-in-class reliability.
• Fast 230mm/Second Print Speed
• Simple Drop-In Paper Loading
• Standard Auto Paper Cutter
• Includes Cables and Power Supply
• Compatible with Most Popular POS Software Applications
• SDK Available for IOS and Android Operating Systems
Features
• Serial, USB and Ethernet Built-In
• Programmable Paper Saving Options
• Auto-Cutter – Selectable Full or Partial Cut
• Drop and Print Paper Loading
• Paper-End Sensor
• Adjustable Paper Near-End Sensor
• No Dip Switches – Intuitive Keypad Programming
• Supports Asian Character Sets with Standard Memory
• Includes Starter Paper Roll, External Power Adaptor and Cord, Paper Width Selector, Quick Reference Manual, Serial Cable and USB Cable
Modify your printer with these easy-to-add options:
• Audio/Visual Print Messenger – for noisy kitchens – alarm sounds and light flashes when a new order is printed.
SPECIFICATIONS
| Print Speed | 230mm /Second (63 Lines/Second) |
| Paper Cutting Method | Auto-Cutter with Selectable Full or Partial Cut |
| Resolution | 180 DPI x 180 DPI |
| Character Per Line | Font A: 42 (72mm) / 33 (58mm), Font B: 56 (72mm) / 45 (58mm) |
| Characters Size | Font A: 12 x 24, Font B: 9 x 17 |
| Paper Supply | Drop and Print |
| Reliability MTBF | 360,000 Hours |
| Reliability MCBF | 18,000,000 Lines |
| Character Set | Alphanumeric: 95, International: 13, Code Pages 56 |
| Bar Code | UPC-A, UPC-E, EAN8, EAN13, Code 39, Code 93, Code 128, ITF PDF 417, CODABAR, QR Code, MaxiCode, GSI |
| Compatibility | ESC/POS |
| Interface | Serial + USB + Ethernet |
| Drivers | Windows 8.1 32 and 64-bit/ Windows 8 32 and 64-bit/ Windows 7 32 and 64-bit/ Server 2012 32 and 64-bit/ Server 2008 32 and 64-bit/ Server 2003 32 and 64-bit/ 2000 Server 32-bit/2000 Server Professional/ Windows Vista 32 and 64-bit / Windows XP Professional 32 and 64-bit / Windows POSReady 2009 32-bit/ Linux CUPS / JavaPOS / OPOS |
| Buzzer | Internal (Standard) |
| Drawer Port | Supports Two 24VDC Drawers w/ Compulsion |
| Data Buffer | Receive Buffer RAM: 64 KB RAM, Bitmap: 128 KB, Flash Bitmap: 512 KB |
| Power Supply | AC 100 ~ 240 V, 50/60 HZ Adapter Included |
| Power Usage | 1.5A/36W |
| Dimensions | 145 mm (W) x 141 mm (H) x 195 mm (D) |
| Shipping Weight | 1.45 Kg |
